SWIR Hyperspectral Camera
Product Code: ATH1010-17

Qty

Request a Quote or Info
application

ATH1010-17 is compact and light SWIR hyperspectral camera fit to be mounted to the drone. With features of high spatial and spectral resolution, wide field imaging.
ATH1010-17 is made of two parts, imaging camera and hyperspetrometer applied transmission grating technology and excellent aberration.
ATH1010-17 SWIR hyperspectral camera uses high resolution & performance cooled InGaAs CCD with 640×512 pixels or 1280×1024 pixels, clear imaging and low noise. ATH1010-17 SWIR hyperspectral camera shape long tube fit to multi-rotor drone. But ATH1010-17L shape bending optical bench design can fit more to fixed wing drone or short landing gear drone.
ATH1010-17 SWIR hyperspectral camera can fit to in field measure spectral information of plants, water, soils, the obtained spectrum used for analysis. The physical and chemical properties of plants build modeling with spectral database to be applied to plants classification, plants growth etc.
With compact design, high resolution, push broom imaging, this SWIR hyperspectral camera can be extended to many application in field, including rotary and indoor scan system, mounted on the drone for remote sensing.

Model

Features

ATH1010-17

640×512 pixels,cooled down to 0℃

ATH1010-17HR

High resolution,1280×1024 pixels,
cooled down to -10℃

ATH1010-17DP

Deep cooled down to -70℃,
640×512 pixels

ATH1010L-17

L-shape design fit to fixed wing drone or with short landing gear

ATH1010L-17HR

L-shape design,1280×1024 pixels,fit to fixed wing drone or with short landing gear

ATH1010L-17DP

L-shape design, cooled down to -70℃,
640×512 pixels
Optical parameter
Working temperature -20 ~ 50°C
Sensor
Pixel Size 15 µm x 15 µm
Detector
Detector model Cooled InGaAs CCD
Dimensions 319 mm × 127 mm × 125 mm
hyperspectral
FOV width (FOV)15.2°@f=35 mm (IFOV)2 mrad@f=35 mm
Slit Width 15 µm,25µm optional
Spectral Range 900~1700nm
Spectral Resolution <4.3nm
Weight 1.45kg
Bit Depth 12 bits~16bits
system parameter
Data output interface USB3.0
Optosky Optical Parameters
SNR 45dB
Optosky Electrical Parameters
Power supply 12V DC,2.5A
Electrical parameter
Storage temperature -30 ~ 70°C

  • Wavelength:900~1700nm
  • Spectral resolution:3.3~4.8 nm
  • Optical bench:PGP design
  • Max. FOV:31.7°
  • Min. FOV:1.2 mrad
  • Excellent imaging quality
  • Advanced algorithm for impression images
  • Compact size
  • Light weight < 1450g
  • No mechanical scan improve reliability

  • Geology and mine exploration
  • Agricultural growth and output appraisal
  • Forestery and plant disease monitor
  • Fire prevention monitor
  • Coastline and sea environment monitor
  • Pasture grass production and growth monitor
  • Lake and river monitor
  • Remote sensing teaching & research
  • Meteorological research
  • Ecosystem protection and mine monitor
  • Water quality, soils monitor
  • Agriculture and animal products quality
  • Military, defense and land security
  • Disaster prevention
