Product Introduction | NY3300Pro Multispectral Agriculture Analyzer: 24/7 Field Guardian

In modern agricultural production, crop growth, pest and disease distribution, and water and fertilizer status often exhibit significant spatial variability and rapid changes. Traditional manual field inspections and fragmented monitoring methods struggle to achieve large-scale, continuous, and precise perception:

Problem detection is delayed, missing the optimal intervention window.

Monitoring dimensions are singular, making it difficult to quantify the true crop status.

Data is fragmented, unable to support refined management decisions.

The NY3300 Pro Multispectral Agriculture Analyzer is a multispectral sensing device launched by Optosky for agricultural digitalization and precision management. Through multi-band spectral acquisition and vegetation index inversion, it achieves continuous monitoring and intelligent analysis of field conditions.

01  Product Performance and Advantages

• Professional Multispectral Configuration, Accurately Capture Crop Information

9 Custom Spectral Channels

450nm,530nm,555nm,650nm,670nm,730nm,800nm,840nm,960nm

Supports customization for other spectral channels

• High-Performance Imaging and Wide-Area Coverage, Balancing Accuracy and Efficiency

33x Optical Zoom, Monitoring Radius Exceeding 1KM

• Intelligent Analysis, Proactive Warning

Early identification of disease spots and pest stress through changes in spectral features, capturing the optimal control window.

Rice Monitoring Image

Platform Alert

• Data Empowerment, Worry-Free Decision-Making

Seamless Integration with Platforms

02  Product Parameters

Multispectral Performance Parameters
Parameter	Details
Spectral Channels	6 bands: 450nm, 530nm, 555nm, 650nm, 685nm, 800nm (bandwidth approx. 15nm each) 9 bands: 450nm, 530nm, 555nm, 650nm, 670nm, 730nm, 800nm, 840nm, 960nm (bandwidth approx. 15nm each) Supports customization for other spectral channels
Index Inversion	More than 30 vegetation index inversions, including Nitrogen Index, Plant Pigment Ratio, Soil Adjustment, Chlorophyll, Anthocyanin, Red Edge Normalized Difference, Vegetation Difference, New Vegetation, Attenuation Index, Physiological Reflectance, Stress Index, Yellowness Index, etc.
Pixel	4 million
Lens Aperture	F1.2
Spectral Resolution	2cm/pixel@1KM
Optical Zoom	33x
Lens Focal Length	5.8mm ~ 192mm
Communication Interface	4G, Wired

03 Multi-Dimensional Data Supporting Precision Agriculture Decisions

The NY3300 Pro Multispectral Agriculture Analyzer, through its continuous, stable, and multi-dimensional spectral sensing capabilities, shifts field condition assessment from “experience-based judgment” to “data-driven decision-making,” providing reliable support for the refined management and sustainable development of modern agriculture.

Widely applicable to:

• Precise Growth Monitoring

Provide field growth distribution maps

• Nutrient Deficiency Diagnosis

Accurate inversion of nutrient content for precision fertilization.

• Early Warning of Pests and Diseases

Early identification of disease spots and pest stress

• Drought and Irrigation Guidance

Monitor crop water stress and assess soil moisture

Application Fields

• Agriculture & Forestry

Real-time monitoring of plant growth and environmental data

• Fisheries & Animal Husbandry

Monitoring of water eutrophication

• Water Resource Testing

Monitor domestic sewage, industrial wastewater, etc. in surrounding water bodies
